Inverter Heat Pump For Swimming Pool, use GMCC full inverter compressor with R32 refrigerant.
It could heating /cooling swimming pool, save energy (COP 4-15), and keep the water temperature stable.
Breeze series Inverter Heat Pump for Small Swimming Pool, is suitable for European residential buildings etc.
The controller support for wifi, you could control it on phone, operation and installation is very simple.
|
Breeze series DC Inverter Swimming Pool Heat pump(R32) |
|||||||||
|
Model |
DSP02PS-P2D |
DSP03PS-P2D |
DSP04PS-P2D |
DSP05PS-P5D |
DSP06PS-P5D |
DSP07PS-P7D |
DSP08PS-P7D |
||
|
Advised pool volume |
25m³-50m³ |
30m³-60m³ |
35m³-70m³ |
60m³-100m³ |
65m³-110m³ |
70m³-130m³ |
80m³-150m³ |
||
|
Operating ambient air temperature |
﹣5℃~43℃ |
﹣5℃~43℃ |
﹣5℃~43℃ |
﹣5℃~43℃ |
﹣5℃~43℃ |
﹣5℃~43℃ |
﹣5℃~43℃ |
||
|
Performance condition 1-Air: 26℃, RH80%, inlet/outlet water temperature: 26℃/28℃ |
|||||||||
|
Heating capacity |
KW |
2.72-11.00 |
3.50-14.20 |
4.24-17.45 |
5.75-23.24 |
6.22-25.13 |
6.62-29.03 |
7.71-31.73 |
|
|
COP |
6.30-14.84 |
6.19-14.66 |
6.00-14.53 |
6.11-14.55 |
6.21-14.55 |
6.12-14.56 |
6.12-14.61 |
||
|
Performance condition 2-Air: 15℃, RH70%, inlet water/outlet temperature: 26℃/28℃ |
|||||||||
|
Heating capacity |
KW |
2.20-8.15 |
2.90-10.70 |
3.55-13.00 |
4.65-17.36 |
5.17-18.55 |
5.46-21.31 |
6.34-23.69 |
|
|
COP |
4.95-7.85 |
4.95-7.65 |
4.85-7.49 |
4.81-7.65 |
4.93-7.55 |
4.97-7.52 |
4.91-7.61 |
||
|
Performance condition 3-Air: 35℃ DB, inlet/outlet water temperature: 30℃/28℃ |
|||||||||
|
cooing capacity |
KW |
2.45-6.00 |
3.25-7.90 |
3.95-9.65 |
5.33-12.83 |
5.85-13.93 |
6.21-16.02 |
7.21-17.52 |
|
|
EER |
4.35-7.35 |
4.40-7.40 |
4.20-7.40 |
4.15-7.25 |
4.18-7.23 |
4.31-7.55 |
4.20-7.45 |
||
|
Refrigerant type |
R32 |
R32 |
R32 |
R32 |
R32 |
R32 |
R32 |
||
|
Power supply |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
230V～, 1Ph, 50Hz |
||
|
Inlet/outlet water pipes |
G1-1/2′ |
G1-1/2′ |
G1-1/2′ |
G1-1/2′ |
G1-1/2′ |
G1-1/2′ |
G1-1/2′ |
||
|
Advised waterflow |
m³/h |
4～6 |
5～7 |
6～8 |
8～10 |
8～11 |
9～12 |
12～15 |
|
|
Dimension |
Unit (W×D×H) |
mm |
991×400×642 |
991×400×642 |
991×400×642 |
1081×450×707 |
1081×450×707 |
1181×469×807 |
1181×469×807 |
|
Packing (W×D×H) |
mm |
1056×449×767 |
1056×449×767 |
1056×449×767 |
1146×498×832 |
1146×498×832 |
1246×518×932 |
1246×518×932 |
|
|
Net/Gross weight |
KG |
44/54 |
46/56 |
56/66 |
70/83 |
72/85 |
90/108 |
98/116 |
|
|
Loading (40HQ/20GP) |
Pcs |
165/77 |
165/77 |
165/77 |
144/44 |
144/44 |
72/32 |
72/32 |
|
|
Notes: |
|||||||||
|
1. Advised pool volume for the pool with isothermal cover. |
|||||||||
|
2. The specification may be changed for product improvement, please refer to the nameplate of product. |
|||||||||
FULL DC Inverter technology:
Stable running and high reliable Adopt full DC inverter technology, the unit can keep more stable running than ON/OFF unit, and keep the temperature of the pool water more accurate.
Soft start design to guarantee the safety of the whole house's electricity supply. When the heat pump start to working, the current will slowly increase from 0A.
ABS Plastic casing, with ASA film, warranty 5 years no colour change.
R32 refrigerant, more eco-friendly
ODP (Ozone Depletion Potential) is 0; GWP (Global Warming Potential) is only 675.
Low GWP value. GWP value is only approximately 1/3 of the GWP of R410A.
Wifi function for our heat pumps, control your heat pump from our special designed App.
With CE certificate issued by TÜV for both LVD testing and EMC testing.
