High Temperature Heat Pump, use well-kown components, Panasonic compressor & R134a refrigerant, or Copeland compressor and R134a refrigerant;
supporting for customized with SS304 /SS316 stainless steel casing.
Commercial High Temperature Heat Pump System suitable for large buildings /projects, such as shool, hospital, restaurant, hotel etc.;
Commercial use high Temperature Heat Pump water heater max water temperature could reach to 80℃, heating capacity could reach to 154KW, the controller supports for master-slave (max 16units) and Modbus communication function, wifi function for option.
|
Volcano series (High temperature air source heat pump water heater circulation type) |
||||||||||||||
|
HT3Ps-E3 |
HT5sP-E5 |
HT3P-E3 |
HT5P-E5 |
HT7P-E7 |
HT10P-E10 |
HT14P-E14 |
HT20P-E20 |
HT24P-E20 |
HT30P-E20 |
HT48P-C96 |
HT60P-C96 |
|||
|
Rated heating capacity |
kW |
8.2 |
13.5 |
8.2 |
13.5 |
17.8 |
26.1 |
34.7 |
55.2 |
64.3 |
78.5 |
129.5 |
153.7 |
|
|
Rated input power |
kW |
2.42 |
3.98 |
2.42 |
3.95 |
5.26 |
7.65 |
10.21 |
16.32 |
19.13 |
23.56 |
38.09 |
45.88 |
|
|
Rated input current |
A |
10.58 |
17.56 |
4.58 |
7.52 |
9.99 |
14.55 |
19.35 |
30.95 |
36.33 |
44.71 |
72.34 |
87.14 |
|
|
Maximum input power |
kW |
3.14 |
5.17 |
3.14 |
5.13 |
6.84 |
9.95 |
13.27 |
21.22 |
24.88 |
30.63 |
47.62 |
57.36 |
|
|
Maximum input current |
A |
14.01 |
23.23 |
5.95 |
9.75 |
13.02 |
19.13 |
24.98 |
40.25 |
46.88 |
57.96 |
90.44 |
108.94 |
|
|
Performance coefficient (COP) |
/ |
3.39 |
3.39 |
3.39 |
3.42 |
3.38 |
3.41 |
3.40 |
3.38 |
3.36 |
3.33 |
3.40 |
3.35 |
|
|
Rated hot water output temp. |
℃ |
75 |
||||||||||||
|
Maximum hot water output temp. |
℃ |
80 |
||||||||||||
|
Rated hot water produce capacity |
△t40 |
L/H |
175.7 |
289.3 |
175.7 |
289.3 |
381.4 |
559.3 |
743.6 |
1182.9 |
1377.9 |
1682.1 |
2795.0 |
3440.0 |
|
△t60 |
L/H |
117.1 |
192.9 |
117.1 |
192.9 |
254.3 |
372.9 |
495.7 |
788.6 |
918.6 |
1121.4 |
1863.3 |
2293.4 |
|
|
Power supply |
1N 220V/50Hz |
3N 380V/50Hz |
||||||||||||
|
Compressor |
Type |
Hermetic scroll type |
||||||||||||
|
Start Mode |
Directly start (Soft start for option) |
|||||||||||||
|
Quantity |
Set |
1 |
1 |
1 |
1 |
1 |
2 |
2 |
4 |
4 |
4 |
4 |
4 |
|
|
Water side heat exchanger |
Type |
Shell & coil (tube) heat exchanger |
||||||||||||
|
Water flow |
m3/h |
1.4 |
2.3 |
1.4 |
2.3 |
3.1 |
4.5 |
6.0 |
9.5 |
11.2 |
13.8 |
22.4 |
27.6 |
|
|
Water Pressure Drop |
kPa |
≤45 |
≤53 |
<50 |
<55 |
<57 |
<60 |
<70 |
<70 |
<72 |
<72 |
<75 |
<75 |
|
|
Pipe size |
mm |
DN20 |
DN25 |
DN20 |
DN25 |
DN25 |
DN32 |
DN32 |
DN50 |
DN50 |
DN50 |
DN80 |
DN80 |
|
|
Protections |
1. High pressure and low pressure protection |
|||||||||||||
|
Refrigerant |
Type |
R134a |
||||||||||||
|
Throttle Type |
Electronic expansion valve |
|||||||||||||
|
Quantity |
kg |
1.9 |
3.3 |
1.9 |
3.3 |
4.3 |
2.8×2 |
4.1×2 |
3.2×4 |
3.8×4 |
4.6x4 |
7.6×4 |
9.2x4 |
|
|
Noise |
DB(A) |
≤55 |
≤63 |
≤55 |
≤63 |
≤65 |
≤68 |
≤68 |
≤70 |
≤70 |
≤72 |
≤74 |
≤75 |
|
|
Dimension |
mm |
700×680×875 |
820×695×1060 |
700×680×875 |
820×695×1060 |
820×695×1360 |
1502×750×1060 |
1502×750×1360 |
1995×1165×1105 |
1995×1165×1105 |
1995×1165×1105 |
2000×2050×1980 |
2000×2050×1980 |
|
|
Net Weight |
kg |
110 |
160 |
110 |
160 |
190 |
255 |
410 |
600 |
755 |
855 |
1250 |
1620 |
|
|
Testing conditions: |
||||||||||||||
|
1. Application side initial water temperature: 15℃, end temperature 75℃, max. temperature 80℃. |
||||||||||||||
|
2. Ambient temperature dry bulb 20℃, wet bulb 15℃. |
||||||||||||||
|
The above parameters are based on Refrigearnt R134a, for parameters based on other refrigerant please contact us. |
||||||||||||||
|
The above parameters may have some differences from the final product because of products updating, so above information is not the provision of any business contract. Please refer to final product label when buy, or refer to us for any information. Our company keeps the right to interpret. |
||||||||||||||
Higher Efficiency
20% higher efficiency by its V-shape and Φ7mm coil in evaporator & blue coating for seaside cities.
With low GWP R134 refrigerant,more green gas for the environment, also with its lower pressure, it is more safe and it can supply higher water output temperature.
Max. 80℃ high water output temperature.
Wifi function for option, you can control your heat pump anytime with the stable mobile app on your phone
The RS485 port and Modbus communication protocol help you to easily link the BMS system, and at the same time, it can control multiple units modularly.
